Ram Front Radius Arm Drop Brackets Synergy MFG
SKU
8730-03-FSVG
List price
$650.00
Price
$650.00
Description
Synergy Ram Truck Radius Arm Drop Brackets improve ride quality by lowering the radius arm mounting locations at the frame to maintain factory front suspension geometry for leveled and lifted trucks. Flippable cam spacers in the drop brackets allow the user to run the axle 1/2 inch forward for leveled trucks or 1-1/2 inches forward to clear larger tires and taller lifts.
Fits: 2014-present RAM 2500/2013-present RAM 3500
Features:
- Improved ride quality by maintaining factory suspension geometry at lifted ride heights.
- Adjustable axle placement for oversized tires and taller lifts.
- Drop brackets lower the front control arm mounting position 3 inches at the frame side.
- Maintains factory geometry on lifted vehicles. Bolt-on design allows installation with simple hand tools.
- CAD designed from heavy duty 3/16 inch steel plate and includes an integrated, crush resistant, grade 50 A-572 steel skid plate.
- Stainless steel flippable cam spacers allow the axle to be located 1/2 inch forward or 1-1/2 inches forward to allow clearance for larger tires and taller lifts.
- Drop brackets do not need to be removed to service the drivetrain.
- Suspension components feature an abrasive resistant powder coat finish for maximum durability and corrosion resistance.
Notes:
- Designed to be used with 2.5 - 6 inch front lift springs.
- Recommend having the truck aligned after installation.
- Running the axle 1-1/2 inches forward may require a driveshaft spacer or lengthened driveshaft.
- Running larger tires with the axle 1-1/2 inches forward will require an aftermarket front bumper or trimming of the stock bumper.
- Running the axle 1-1/2 inches forward may require sway bar relocation brackets.
Video
0 array:5 [ "#type" => "html_tag" "#tag" => "iframe" "#attributes" => array:7 [ "src" => "https://ratchetsoffroad.com/media/oembed?url=https%3A//youtu.be/40Ti7W6lG6A&max_width=0&max_height=0&hash=RaOA_4HG9zwtOfQIfr7ToecabOT7p6luhkczPtjtDbs" "scrolling" => false "width" => 600 "height" => 339 "class" => array:1 [ 0 => "media-oembed-content" ] "loading" => "lazy" "title" => "Synergy Manufacturing" ] "#attached" => array:1 [ "library" => array:1 [ 0 => "media/oembed.formatter" ] ] "#cache" => array:3 [ "contexts" => [] "tags" => array:1 [ 0 => "config:media.settings" ] "max-age" => -1 ] ]
Fitment
Vehicle Fitment
2013-2018 Ram 3500 Big Horn
2013-2018 Ram 3500 Laramie Longhorn
2013-2018 Ram 3500 Tradesman
2013-2013 Ram 3500 ST
2013-2018 Ram 3500 SLT
2013-2015 Ram 3500 Lone Star
2013-2018 Ram 3500 Laramie
2014-2015 Ram 2500 Laramie Limited
2014-2018 Ram 2500 Laramie Longhorn
2014-2018 Ram 2500 Big Horn
2014-2015 Ram 2500 Lone Star
2014-2016 Ram 2500 Outdoorsman
2014-2018 Ram 2500 Power Wagon
2014-2015 Ram 3500 Laramie Limited
2014-2018 Ram 2500 SLT
2014-2018 Ram 2500 Laramie
2014-2018 Ram 2500 Tradesman
2016-2018 Ram 3500 Limited
2016-2018 Ram 2500 Limited
2017-2017 Ram 3500 Lone Star
Installation
Installation Instructions
8730-03-INST.A.pdf
(1.49 MB)
Specs
Specs
Country of Origin: USA
UPC: 00887753146366
Location: Front
Harmonized Tariff Code: 8708807000
Category
Hardware
Suspension / Steering / Brakes
Tabs, Gussets & Brackets
Suspension
Control Arm Brackets
Suspension Control Arm
Control Arm Mount
Brand
Synergy MFG
Vehicle Type
Truck/SUV
